HDPV120 / HDPV232 DC Photovoltaic Fuse with Indicator | 20A–32A | 1500VDC Solar PV Protection
The Delixi HDPV120 / HDPV232 DC Fuse with Indicator is a high-performance protection solution designed specifically for photovoltaic (PV) systems, solar power installations, and DC distribution applications. Engineered to provide reliable overcurrent protection, this fuse series safeguards solar modules, battery storage systems, combiner boxes, and DC circuits from overload and fault conditions.
Featuring an integrated indicator mechanism for quick fuse status identification, the HDPV series improves maintenance efficiency and system reliability in renewable energy environments.
Designed according to international safety standards, these DC photovoltaic fuses deliver dependable circuit protection in high-voltage DC systems up to 1500VDC.
Key Features:
✔ Designed specifically for solar photovoltaic (PV) and DC applications
✔ Available current ratings: 20A and 32A
✔ Rated operating voltage up to 1500VDC
✔ Integrated fuse status indicator for simplified maintenance
✔ High breaking capacity up to 33kA
✔ Reliable overcurrent and fault protection
✔ Compact DIN rail compatible design
✔ Suitable for solar combiner boxes and battery protection systems
✔ Designed according to IEC/EN 60269 / IEC 60947-3 standards
Technical Specifications:
| Parameter | Specification |
|---|---|
| Product Series | HDPV120 / HDPV232 |
| Product Type | DC Fuse with Indicator |
| Rated Current (In) | 20A, 32A |
| Pole Configuration | 1 Pole (1P) |
| Breaking Capacity | 20kA – 33kA |
| Operating Voltage | 1000VDC / 1500VDC |
| Protection Type | Overcurrent Protection |
| Application | Solar PV and DC Systems |
| Standard Compliance | IEC/EN 60269 / IEC 60947-3 |
Available Models:
CDPV1
-
Rating: 20A
-
Description: Fuse Disconnector
-
Operating Voltage: 1000VDC
CDPV1-20X
-
Rating: 20A
-
Description: Photovoltaic Fuse Base
-
Operating Voltage: 1000VDC
-
Breaking Capacity: 20kA
CDPV2-32G / 32A
-
Rating: 32A
-
Description: Fuse Disconnector
-
Operating Voltage: 1500VDC
CDPV2-32 20A
-
Rating: 20A
-
Description: Photovoltaic Fuse
-
Operating Voltage: 1500VDC
-
Breaking Capacity: 33kA
CDPV2-32 32A
-
Rating: 32A
-
Description: Photovoltaic Fuse
-
Operating Voltage: 1500VDC
-
Breaking Capacity: 33kA
Applications:
-
Solar photovoltaic (PV) systems
-
Solar combiner boxes
-
Battery energy storage systems (BESS)
-
Renewable energy infrastructure
-
Industrial DC distribution systems
-
DC power protection installations
The Delixi HDPV DC Fuse Series delivers reliable overcurrent protection, fault isolation capability, and enhanced safety for modern solar and high-voltage DC electrical systems.
