HPYF Miniature Relay Base – Reliable Socket for CDZ9 Relay Installation
The Delixi HPYF Miniature Relay Base is a high-quality relay socket designed for the installation and secure mounting of CDZ9 miniature relays. It provides a reliable electrical connection while allowing quick relay replacement and easy maintenance in industrial automation, control panels, PLC systems, and electrical control applications.
Available in both 8-pin and 14-pin configurations, the HPYF relay base simplifies relay installation and wiring while ensuring stable operation in demanding industrial environments. Designed according to IEC 60947-4 standards, it is suitable for use with relays rated up to 690V and 3A, 5A, and 10A applications.
Its compact design and DIN rail compatibility make it an essential accessory for automation panels, machine control systems, and industrial electrical installations.
Key Features
✔ Compatible with Delixi CDZ9 miniature relays
✔ Available in 8-pin and 14-pin socket versions
✔ Supports relay ratings of 3A, 5A, and 10A
✔ Quick plug-in relay installation and replacement
✔ Secure electrical contact and reliable operation
✔ Compact space-saving design
✔ Suitable for industrial control panels
✔ Simplifies wiring and maintenance
✔ Durable insulation material
✔ DIN rail and panel mounting compatible
✔ IEC 60947-4 compliant
✔ Long service life and high reliability
Technical Specifications
| Parameter | Specification |
|---|---|
| Series | HPYF |
| Product Type | Miniature Relay Base / Relay Socket |
| Compatible Relay Series | CDZ9 Miniature Relay |
| Pole Options | 2P, 3P, 4P |
| Current Ratings | 3A, 5A, 10A |
| Rated Voltage | Up to 690V |
| Pin Options | 8 Pin / 14 Pin |
| Standard | IEC 60947-4 |
| Mounting Type | Panel / DIN Rail Mount |
Available Variants
5A Models
-
CDZ9-54P Base – 5A – 8 Pin
-
CDZ9-54P Base – 5A – 14 Pin
10A Models
-
CDZ9-54P Base – 10A – 8 Pin
-
CDZ9-54P Base – 10A – 14 Pin
Applications
-
PLC control panels
-
Industrial automation systems
-
Motor control circuits
-
Machine control equipment
-
HVAC control systems
-
Power distribution panels
-
Electrical switchboards
-
Building management systems
-
Process automation
-
Control and monitoring systems
Why Choose the Delixi HPYF Relay Base?
The Delixi HPYF Relay Base provides a secure, reliable, and maintenance-friendly mounting solution for CDZ9 miniature relays. Its plug-in design allows quick replacement without rewiring, reducing downtime and improving efficiency in industrial automation and electrical control systems.
Compatible Products
-
Delixi CDZ9 Miniature Relays
-
Delixi CJX2 Magnetic Contactors
-
Delixi CDCH8S Modular Contactors
-
Delixi JRS1DSP Thermal Overload Relays
-
Delixi Industrial Control Components
