DZ47s Miniature Circuit Breaker (MCB) 6kA | 1P, 2P, 3P & 4P | 1A–63A
The Delixi DZ47s Miniature Circuit Breaker (MCB) is a compact and reliable protection device designed to safeguard electrical circuits against overloads and short circuits. Engineered with high-quality components and built according to international safety standards, the DZ47s series provides dependable protection for residential, commercial, and industrial electrical installations.
Featuring an 18mm compact design, multiple pole configurations, and various current ratings, the DZ47s series offers flexibility for a wide range of power distribution applications.
Key Features:
✔ Compact 18mm modular design
✔ Available in 1 Pole (1P), 2 Pole (2P), 3 Pole (3P), and 4 Pole (4P) configurations
✔ Current ratings from 1A to 63A
✔ High 6kA breaking capacity
✔ Available tripping curves: B Curve, C Curve, and D Curve
✔ Protection against overload and short circuit faults
✔ DIN rail mounting for quick installation
✔ Suitable for residential, commercial, and industrial power systems
✔ Manufactured according to IEC 60898-1 international standards
Technical Specifications:
| Parameter | Specification |
|---|---|
| Product Series | DZ47s |
| Product Type | Miniature Circuit Breaker (MCB) |
| Module Width | 18mm |
| Rated Current (In) | 1A, 2A, 4A, 6A, 10A, 16A, 20A, 25A, 32A, 40A, 50A, 63A |
| Pole Options | 1P, 2P, 3P, 4P |
| Breaking Capacity | 6kA |
| Tripping Curve | B, C, D Curves |
| Installation Type | DIN Rail |
| Standard Compliance | IEC 60898-1 |
Available Models:
DZ47SN1C – 1 Pole (1P)
-
Current Ratings: 2A / 6A / 10A / 16A / 20A / 25A / 32A / 40A / 63A
-
Breaking Capacity: 6kA
DZ47SN2C – 2 Pole (2P)
-
Current Ratings: 6A / 10A / 16A / 32A / 40A / 63A
-
Breaking Capacity: 6kA
DZ47SN3C – 3 Pole (3P)
-
Current Ratings: 6A / 10A / 16A / 20A / 32A / 40A / 63A
-
Breaking Capacity: 6kA
DZ47SN4C – 4 Pole (4P)
-
Current Ratings: 10A / 16A / 20A / 25A / 32A / 40A / 63A
-
Breaking Capacity: 6kA
The Delixi DZ47s MCB Series delivers efficient electrical protection, operational reliability, and compact installation for modern power distribution systems.
