CDM3V Battery Protection MCCB | 125A–250A | 3 Pole (3P) | 25kA–35kA Breaking Capacity | IEC 60947-2
The Delixi CDM3V Molded Case Circuit Breaker (MCCB) is specifically engineered for battery protection applications, providing reliable circuit isolation and protection against overloads and short-circuit faults in battery energy systems and DC power environments.
Designed for demanding energy storage applications, the CDM3V series delivers dependable performance, high fault interruption capability, and enhanced operational safety for battery banks, energy storage systems (ESS), renewable energy infrastructure, and industrial power distribution networks.
With a robust molded case construction and high 35kA breaking capacity, the CDM3V provides secure protection for critical electrical systems where reliability and system continuity are essential.
Key Features:
✔ Designed specifically for battery protection systems
✔ Available current ratings: 125A and 250A
✔ 3 Pole (3P) configuration
✔ High breaking capacity: 25kA – 35kA
✔ Reliable overload and short-circuit protection
✔ Heavy-duty molded case design for durability and long service life
✔ Suitable for battery energy storage systems and industrial applications
✔ Fast fault isolation capability for enhanced safety
✔ Manufactured according to IEC 60947-2 standards
Technical Specifications:
| Parameter | Specification |
|---|---|
| Product Series | CDM3V |
| Product Type | Molded Case Circuit Breaker (MCCB) |
| Application | Battery Protection |
| Rated Current (In) | 125A, 250A |
| Pole Configuration | 3 Pole (3P) |
| Breaking Capacity | 25kA – 35kA |
| Protection Type | Overload and Short Circuit Protection |
| Installation Type | Fixed Mount |
| Standard Compliance | IEC 60947-2 |
Available Models:
CDM3V – 125A
-
Pole Configuration: 3 Pole (3P)
-
Breaking Capacity: 35kA
CDM3V – 250A
-
Pole Configuration: 3 Pole (3P)
-
Breaking Capacity: 35kA
Applications:
-
Battery Energy Storage Systems (BESS)
-
Solar photovoltaic battery systems
-
Renewable energy infrastructure
-
Industrial battery protection systems
-
DC distribution systems
-
Energy management and backup power installations
The Delixi CDM3V Battery Protection MCCB Series delivers reliable battery circuit protection, high fault interruption performance, and enhanced safety for modern energy storage and industrial power systems.
